pcclcd2-14d-q
PANDUIT LCD2-14D-Q CULUGSBW,2HOLE,#2AWG,1/4,1PKG
pcclcd2-14d-q
PANDUIT LCD2-14D-Q CULUGSBW,2HOLE,#2AWG,1/4,1PKG
Manufacturer:PANDUIT
Manufacturer #:LCD2-14D-Q
Description
Two-hole, standard barrel lug with window, #2 AWG wire, 1/4 stud hole, 1 hole spacing.
Specifications
| Brand Name | Panduit | Sub Brand | Pan-Lug™ |
| Item Name | Copper Compression Lug | Type | Compression Lug |
| Conductor Size | 2 AWG | Number of Holes | 2 |
| Stud Size | 1/4 in | Barrel Length | 0.88 in |
| Tongue Size | 0.6 x 0.1 in | Overall Length | 2.77 in |
| Color Code | Brown | Material | Copper |
| Series/Model | LCD | Voltage Rating | 35000 V |
| Barrel Type | Standard Barrel Length with Inspection Window | Tongue Type | Standard |
| Stud Hole Spacing | 1 in | Finish | Tin Plated |
| Standards | C22.2 No. 65-13 | UPC | 074983383009 |
