EATON 10250T206NC1N-POP 30-1/2 mm Indicator Light Red 24 VAC/VDC, Heavy Duty Watertight/Oiltight, Full Voltage, Standard Actuator
Description
Full voltage 24 Vac/Vdc with two extra lenses: Green and amber. Also includes two square engraved legend plates: RUN and JOG.
Specifications
Brand Name | Eaton | Item Name | 30-1/2 mm Indicator Light |
Type | Heavy Duty Watertight/Oiltight, Full Voltage, Standard Actuator | Voltage Rating | 24 VAC/VDC |
Lamp Type | Incandescent | Lens Color | Red |
Series/Model | 10250T | Nominal Diameter | 30.5 mm |
Lens Material | Plastic | Enclosure Type | NEMA 3, 3R, 3S, 4, 4X, 12, 13 |
Dimensions | 7.0000 IN X 6.0000 IN X 3.0000 IN | Standards | UL Listed,CSA Certified,CE Marked |
UPC | 782114408537 |
